What Are Industrial Shredders?

Industrial Shredders

Many companies struggle with the disposal of oversized waste piles. Where to take it, how to dispose of it, how to become more eco-friendly? In recent years, many businesses have invested in industrial shredders to solve many of these problems. But really, what is an industrial shredder and why do you need one?

Industrial Shredders are high-powered machines used to cut through and destroy the toughest debris in all types of environments. Buyer beware though – not all waste is created equal and should not be treated the same. The size, shape and material composition can have a significant impact on the ideal grinder or shredder that is chosen in your facility.

Ensuring there is enough power and cutting force to achieve your overall goal is key.  Inspecting and performing routine check-ups on the operating speed and torque of the shredder or grinder is very important for functionality.  Industrial shredders have a slow speed, high torque processing power, specifically designed to decreases the energy intake, leading to less stress on the motor. The slow rotating speed and high torque of the shaft generated by these shredders are effective across various types of waste in both wet and dry applications. Due to their versatility, a wide range of styles and sizes are available. So, what type of shredder will fit your needs

Hopper Fed Industrial Shredders

Monster Industrial SHRED Series

3-SHRED, 4-SHRED

Hopper-fed shredders, which shear (uses a scissor-type motion to cut through solids) are ideal for industrial environments. The Hopper Fed SHRED Series are industrial shredders that can handle a variety of different materials and shred them down to size. These shredders are customizable to ensure they can meet the needs of a variety of applications.  Whether you need particle size reduction, product destruction, feedstock preconditioning, these shredders can be customized to meet your application’s exacting needs!

JWC offers the 1-SHRED3-SHRED, 4-SHRED and the 7-SHRED. So no matter what throughput or torque you require we have a shredder to meet your needs.

The SHRED Series waste grinders are responsible for quickly cutting various problem solids down to size. When operating an industrial shredder, the material is placed into the hopper, which feeds the material down to the shredder’s two rows of sharp, steel cutters that are slowly rotating.  The cutters grab the material and then pull the material through to turn the large solids into small pieces.

The 1-SHRED grinder is a compact shredder that is tough on solids.  This small industrial shredder fits into areas with limited space requirements, while still providing the necessary power to cut down tough food waste, small bones, wood or even occasional flatware.

The 3-SHRED application is a medium-sized shredder. These waste grinders are designed to easily cut through debris that typically causes problems such as wood, glass, fish processing waste, food waste and much more.

The 4-SHRED-1 & 7-SHRED-1 are designed for some of the most difficult grinding jobs in industrial environments. A wide variety of materials from food waste to plastic to clothing to bricks and ceramic tile are easily ground up with these tough shredders. The strong shafts and heavy-duty seals can quickly shred items down to size. This size reduction equipment has been successful in numerous applications including shredding for recycling, preconditioning of organics for waste-to-energy operations, hazardous waste disposal, seafood processing and destruction of off-specification or contraband products, just to name a few.

Components of Industrial Shredders

Two Shafts

The two shafts of sharp steel cutter teeth are rotated at different speeds creating a scissor-like cutting motion and focuses on slicing waste into small particles, this ensures that the waste is consistently chopped up to appropriate sizes.  The waste is dropped into the cutters and within seconds, the waste is processed and destroyed. When cutter shafts are programmed at low speeds, less shock is created, making this a top speed for grinding difficult objects. The motor’s peak torque can be delivered to the cutters in a more controlled and efficient manner as opposed to high-speed systems.

Individual Cutters

Industrial shredder cutters are available in a variety of sizes – the 3, 7, 11, 13, and 23 tooth options. The thickness of the cutters and the number of teeth within the grinder will alter the particle sizes.  All cutters are available in stainless steel to allow for exposure in harsher environments.

The ability to replace cutters without sending the whole grinder in for maintenance or calling a maintenance team to service the grinder saves time and money for all parties involved.  The individual cutter was designed for swapping out cutters easily and efficiently. Simply lift the shaft of the grinder and replace the cutters!  This lowers the maintenance of the grinder, allows for easy replacement of cutters and creates a faster turnaround time to get the grinder back up and running.

Motor

A variety of motors are offered for the SHRED Series grinders to ensure the system meets your application’s needs.

  • Totally enclosed fan-cooled electric (TEFC).
  • XPFC: Explosion-proof fan-cooled electric.
  • XPNV: Exclusive electric immersible.
  • Hydraulic Drives available in: 2, 3, 5, 10 HP (1.5, 2.2, 3.7, 7.5 kW). Hydraulic Power Packs
  • Available in 5, 10, 15 HP (3.7, 7.5, 11 kW)
  • Or, plug into an onboard hydraulic system using JWC’s control valve.
  • Motor Gear Reducer

Gear-reducers, also known as speed reducers, are a component of many mechanical, electrical, and hydraulic motors. Reducers are used to change the speed of the drive shaft. Through the use of different reducer ratios, the drive shaft speed can be adjusted to either provide more torque or to adjust the throughput of industrial shredders. If you need to grind a very tough material that needs a lot of torque, you can select different horsepower motors, and/or change the gear reducer to achieve the torque you need. If you need higher throughput, then the reducer could be adjusted to increase the speed at which the cutters rotate. All JWC shredders have reducers as all our industrial shredders rotate at a very slow speed.

How do industrial shredders work?

Shredded materials

Based on the throughput, cutter force and particle size that your industry is trying to achieve, there is a shredder that will accomplish your goal. Our shredders’ throughput range is from 40 ft3/hr to 1500 ft3/hr. The cutting force will be determined by the type of solid and strength of the material that is being shredded. We often recommend testing the material being shredded to ensure that the industrial shredder is specified to meet the precise needs of your application. Our motor sizes range from 5hp to 100hp.

Why are Industrial Shredders used?

The main usage for industrial shredders is the ability to reduce the size of waste that is being destroyed and protect pumps and equipment from damage. With so many harsh products being destroyed, it is necessary to start protecting your equipment before it is too late. Industrials shredders can shred debris large or small, hard or soft. Once the debris or waste has been shredded, there are various options for the remains. In many instances, the remains are recycled and used for feedstock preconditioning for digesters, composting or even manufactured into different products. With the increase in hauling and landfill fees, many companies have converted to grinding!

Benefits of Industrial Shredders:

  • Low energy consumption
  • High torque to break up tough objects
  • High Throughput
  • Reduces unplanned process downtime & maintenance costs

What Industries Use Industrial Shredders?

Industrial Shredders are working every day protecting pumps, destroying debris or just making things work better. They are found in applications like recycling, waste to energy, commercial facility sewage, food processing, and oil & gas – just to name a few.  JWC grinders have been installed in various types of environments. CLICK HERE to read about how the 3-SHRED grinder uses two rows of sharp steel cutters to grab material and pull it into the grinder for size reduction.
